To replace your Honda Fit headlights, you’ll need to disconnect the battery, then remove the bumper’s push clips and Phillips screws to access the assembly. Extract four 10 mm bolts securing the headlight housing and disconnect three electrical connectors. Release the spring retaining clip to remove the old bulb, install the new one using nitrile gloves to avoid contamination, and reassemble in reverse order. The procedure varies between first-generation (2001–2008) and second-generation (2007–2015) models, with specific techniques that can streamline your workflow.
Gather Your Tools and Prepare the Workspace
Before removing or replacing Honda Fit headlights, assemble a complete toolkit and establish a safe, organized workspace to prevent delays and minimize the risk of component damage. Gather a 10 mm socket set, Phillips #2 screwdriver, and flat-blade trim pry tool for fastener removal. Position magnetic or clip-on workspace lighting to illuminate the wheel well and engine bay, guaranteeing you’ll see connector access points clearly. Place a labeled parts tray nearby for tools organization and fastener tracking. Disconnect the battery negative terminal before starting electrical work. Verify you’re on a level surface with the parking brake engaged and engine fully cooled. Keep nitrile gloves, replacement bulbs, and dielectric grease within reach. Consult your owner’s manual to identify the correct replacement bulb specifications for your Honda Fit model year. Assure adequate clearance around the vehicle for fender liner removal or jack-stand placement if necessary. To maintain the clarity and brightness of your new headlights after installation, consider applying protective clear coats to guard against oxidation. After headlight replacement, consider applying UV sealant protection to extend the clarity and lifespan of your new headlights.
【Perfect Fit for Honda Fit】The package includes 4pcs bulbs for fog light high/low dual beam bulbs combo, perfectly compatible with Honda Fit 2006 2007 2008 2009 2010 2011 2012 2013 2014 2015 2016 2017 2018 2019 2020 original halogen bulb replacement[Note: The same vehicle model may use xenon or halogen lamps, if your bulb is xenon light, it is not suitable for replacement and only suitable for halogen bulb replacement]
FIT THE FOLLOWING VEHICLE - W3T19371 ballast replacement for 2006-2014 Acura TL TL-S | 2006-2014 Acura TSX | 2012-2014 Acura ILX | 2010-2013 Acura ZDX | 2013-2014 Acura RDX | 2010-2013 Acura MDX | 2009-2011 Acura CSX | 2011-2013 Honda CR-Z | 2004-2014 Honda Odyssey | 2012-2014 Mazda CX-5 | 2007-2012 Mazda CX-9 | 2007-2009 Mazda 3 | 2009-2012 Mazda 5 | 2007-2009 Mitsubishi Out lander | 2008-2012 Mitsubishi Lancer Evolution
【Up to 1500% More Light – Unmatched Nighttime Clarity】Each Termitor H11/9005 light bulb kit packs 16 high-output CSP LEDs, boosting brightness by up to 15 times compared to standard halogens. The crisp 6500K cool-white beam improves road visibility and eases eye fatigue, so you can spot hazards farther ahead and drive more assuredly in any dimly lit environment.
Remove the Headlight Assembly
With your workspace prepared and battery disconnected, begin headlight assembly removal by accessing the radiator shield. Use your trim tool from the tools checklist to remove push clips connecting the shield to the bumper. Pry fasteners under the outer ring, then lift off the shield. Remove the Phillips #2 screws above both front tires at the bumper-side panel junction.
For ideal workspace organization, remove clips attaching the bumper to the headlight bracket with a solid outward pull on each side. Use a 10 mm socket with extension to remove four bolts: one underneath the headlight, one on the side, and two at the top. Remove any Phillips screws on the fender side. Once freed, tilt the headlight assembly for wire access. Disconnect three electrical connectors by squeezing clips and pulling. The passenger side headlight follows the same removal process. Extract the complete assembly.
Replace the Headlight Bulb
Replacing the headlight bulb requires no tools for most Honda Fit models, making this a straightforward 2-5 minute procedure when performed correctly. After disconnecting the electrical connector and removing the rubber splash guard, release the spring retaining clip with a downward and upward motion. Pull the old bulb straight out, noting the three-prong orientation with the middle prong facing upward. Apply proper bulb maintenance techniques by wearing gloves to prevent skin oils from contaminating the glass surface. Align the new bulb’s prongs identically to the old configuration, then insert and secure with the spring clip until you feel resistance. The bulb orientation features a larger tab on top and two smaller tabs on the bottom that must be properly matched during installation. Reconnect the harness and test both low and high beams for headlight brightness comparison, ensuring ideal illumination before completing your replacement.
Lights Dim Over Time, Replace In Pairs: Your lights are a pair, one is never turned on without the other. If one bulb burns out, the other isn't far behind. Replace your 9003 XtraVision Halogen bulbs in pairs for optimum performance.
Lights Dim Over Time, Replace In Pairs: Your lights are a pair, one is never turned on without the other. If one bulb burns out, the other isn't far behind. Replace your 9003 SilverStar Halogen bulbs in pairs for optimum performance.
【300% BRIGHTER】Fit for honda fit headlight bulbs high and low beam 9003 headlight bulbs. Upgraded halogen headlight bulbs with higher quality materials can increase the brightness by 300%, 5000K white light allows you to drive for long periods of time without feeling harsh.
Reinstall the Headlight Assembly
Reinstalling the Honda Fit headlight assembly requires systematic attention to fastener sequence and alignment to achieve factory-spec fitment and prevent lens damage. Begin with a dry-fit test to confirm alignment pins and mounting ears seat properly into fender slots. Perform a thorough assembly inspection of wiring harness reach, connector clearance, and bumper interface gaps before securing hardware. Hand-thread the top and inner 10 mm bolts first, leaving them loose to allow positional adjustment. Insert remaining bolts, then tighten in cross-sequence—top and inner first, followed by side and lower fasteners. Apply moderate torque to avoid cracking plastic mounting bosses. Verify uniform perimeter gaps and complete headlight alignment checks. Before reconnecting electrical connectors, apply dielectric grease for protection against moisture and corrosion. Reconnect electrical connectors bottom-to-top, ensuring retaining tabs engage fully. To prevent premature bulb failure during operation, avoid direct contact with the bulb glass when handling components during reassembly. Reinstall bumper clips and verify lens-to-bumper interface.
Two Functions: This clip remover tool handles two common garage tasks with ease. One end works like a pry bar to pop off headlight covers and trim panels, while the other end grips and pulls out plastic fasteners, rivets, and upholstery clips. You can also use it to move wiring harnesses without causing any damage
【VEHICLE COMPATIBILITY】Headlight Assembly Compatible With 2003-2007 Honda Accord 2/4 Door. Bulbs are not included. High beam bulb type: 9005; Low beam bulb type: 9006. OEM Part Number: 33101-SDA-A01, 33151-SDA-A01. ABPA Partslink Number: HO2503120, HO2502120.
[Vehicle Fitment]: Compatible with Honda Pilot 2006-2008 V6 3.5L, Fit 2007-2008 L4 1.5L (Sport Model) --- It fits the model with Fog Lights Operator
Model-Specific Tips and Variations
Honda Fit headlight replacement procedures vary considerably across model generations, requiring year-specific knowledge of fastener locations, access methods, and bulb configurations. First generation features (2001–2008) necessitate fender-liner removal to access the headlight assembly from behind, requiring push-pin extraction and approximately 20–30 minutes per side. Second generation differences (2007–2013) include simplified rear access through a rubber splash cover with three latches and tool-free spring-clip bulb retention. Full assembly removal on second-gen models requires four 10 mm bolts plus bumper/trim fastener removal. The 2010 Honda Fit demonstrates a straightforward passenger side replacement process that requires minimal tools and can be completed quickly. Later variants (2014–2015) may incorporate projector halogen, HID, or LED configurations requiring VIN verification before ordering replacement components. Always match bulb prong orientation and test function before reinstalling protective covers to avoid repetitive disassembly.
